The new TC5.30 is the most productive multi-crop harvester in its segment. Perfectly at home in any field, whether harvesting small grains such as wheat or barley, specialist crops including rice, sunflower, sorghum or large grains such as corn, soybeans and a broad range of pulse crops. The new five strawwalker model features a best-in-class 1,300 mm wide and 607 mm diameter threshing drum, a double cascaded cleaning shoe with a pre-sieve, a 3500 litre grain tank with an enclosed 3.85m unloading auger and can be paired with the 15ft High-Capacity header. Furthermore, the model delivers the lowest total cost of ownership in its segment. The result? The highest capacity in its segment.
| Maize headers | |
| Heavy duty driveline (2HC powerbelt) | Standard |
| Rigid maize header | 5 row |
| Rotary dividers | NA |
| Cab | |
| Mechanically suspended seat | Standard |
| Instructor’s seat | Optional |
| Air-conditioning | Standard |
| Remote controls for header, threshing and unloading engagement | Standard |
| cab heating | Optional |
| Threshing drum | |
| Width (mm) | 1300 |
| Diameter (mm) | 607 |
| Speed range (rpm) | 387 - 1012 |
| Electric drum speed control | Standard |
| Drum concave | |
| Area (m2) | 0.79 |
| Number of bars | 14 |
| Angle of wrap (degrees) | 111 |
| Concave adjustment | Manual |
| Rotary Separator | Optional |
| Diameter (m) | 0.605 |
| Speed (rpm) | 760 or 400 |
| Concave area (including rake) (m2 ) | 0.83 |
| Multi-Thresh™ concave | Standard |
| Strawwalkers | |
| Number | 5 |
| Separation area with Rotary Separator (m2 ) | 4.5 |
| Separation area with Rotary Separator (m2 ) | 5.3 |
| Cleaning | |
| Total sieve area under wind control (m2) | 3.97 |
| Double Cascade cleaning shoe with extra pre-sieve | Standard |
| Cleaning fan speed range (rpm) | 325 to 927 |
| Cleaning fan speed control | Manual |
| Graintank | |
| Volume (l) | 3500 |
| Unload capacity (l/sec) | 65 |
| Engine | |
| Displacement (l) | 5.9 |
| Emission level | Tier 3 |
| Injection system | Mechanical injectors |
| Gross power ECE R120 (2000 rpm) [kW/hp(CV)] | 96,35/131 |
| Air compressor kit | Optional |
| Fuel tank capacity (l) | 300 |
| Transmission | |
| Traction | Mechanical |
| Speeds | 4 forward, 1 reverse |
| Ground speed (km/h) | 25 |
| Tracks | Optional |
| Front TW 18.4-30 14PR - Rear SW 9.00-16 16PR | Standard |
| Front TW 23.1-26-14PR-TD0 - Rear SW 12.0/75-18 12PR TR-03 | Optional |
| Models | |
| High-Capacity grain header | |
| Cutting width (m/ft) | 4.57/15 |
| Knife speed (cuts/min.) | 1150 |
| Electric reel speed control | Standard |
| Hydraulic reel height control | Standard |
| Reel fore-aft control | Manual |
