Kubota mini excavator pursues customer satisfaction, evolves and gives you the best performance.
Kubota U17-3 Excavator
Kubota mini excavator pursues customer satisfaction, evolves and gives you the best performance.
Kubota U17-3 Excavator
Kubota mini excavator pursues customer satisfaction, evolves and gives you the best performance. When you have to take on a tough job in a tight space, look no further than the versatile U17-3. This compact excavator delivers necessary power, required control, and smooth performance.
Model
U17-3
Bucket capacity m3
0.04
Std.bucket width: (with/without cutting blade) mm
450 / 400
Machine weight (rubber/steel crawler) kg
1820
Operating weight (including operator weight: 75kg) (rubber/steel crawler) kg
1895
Dimensions
(In transport condition)
Overall length mm
Overall height mm
Overall width mm
Min. ground clearance mm
3545
2340
990 / 1240
150
Engine
Mode
Total displacement cc
Rated output (SAE J1995 gross) kW (HP)/rpm
Kubota D902-K3A
898
11.8(16.0) / 2300
Working range
Max. digging height mm
Max. dumping height mm
Max. digging depth mm
Max. vertical wall digging depth mm
Max. digging radius mm
Boom swing (left/right) deg
Min. turning radius (with swing) mm
Min. tail turning radius mm
Max. breakout force (bucket) kN (kgf)
3540
2440
2310
1910
3900
65 / 58
1440 (1210)
620
15.2 (1545)
Track type
Rubber / Steel
Track width mm
230
230
Travel section
Crawler length mm
Tumbler distance mm
Travel speed (1st/2nd gear) km/h
Max. climbing angle deg
1585
1230
2.1/4.1
30
Swing speed rpm
9.1
Blade
Width mm
Height mm
Max. lift above ground/drop below ground mm
990 / 1240
265
260 / 190
Hydraulic pump type
Variable pump x 2
+ gear pump x 1
Swivel motor type
Orbit motor
Travel motor type
Hydraulic piston motor: 2F
Travel motor type L
19
When you have to take on a tough job in a tight space, look no further than the versatile U17-3. This compact excavator delivers necessary power, required control, and smooth performance.
