Model	U50-5S
Bucket capacity   m	0.16
Std. bucket width: (with/without cutting blade)  mm	650 / 600
Operating weight </br> (Including operator weight: 75kg) Canopy (rubber/steel crawler)   kg Cabin (rubber/steel crawler)  kg	4780 / 4865  4855 / 4940
Engine</br> Model    Canopy</br>  Cabin Total displacement   cc Rated output    Canopy  kW (HP) / rpm Cabin kW (HP) / rpm	Kubota V2203-M-E3-BH-BR2  Kubota V2203-M-E2-BH-BR1  2197 28.8 (38.6) / 2250  28.5 (38.2) / 2250
Working range</br> Max. digging height    mm Max. dumping height     mm Max. digging depth    mm Max. vertical wall digging depth    mm Max. digging radius     mm Boom swing (left/right)     mm Min. turning radius (with swing)     mm  Min. tail turning radius     mm Max. breakout force (bucket)  kN (kgf)	5630 4000 3560 2890 5995 70/50 2375 (1875)  990< 36.5 (3720)
Track type	Rubber / Steel
Track width   mm	400
Travel section Crawler length   mm Tumbler distance   mm Travel speed (1st/2nd gear)    km/h   Max. climbing angle     degree	2500 1990 2.5/4.4 < 30
Swing speed   rpm	8.6
Blade  </br> Width  mm</br> Height  mm</br> Max. lift above ground/drop below ground   mm</br>	1960</br> 360</br> 455 / 375
Hydraulic pump typeulic pump type	Variable pump × 1 + gear pump × 1
Swivel motor type	Hydraulic piston motor
Travel motor type	Hydraulic piston motor: 2F
Fuel tank capacity	64
